Software Development – High Definition Pro Telecine – Custom Telecine Systems Design Pro Video Calibration and Test Software Tools – 3D Print Services Real-time Color Cube Gamut scopes – Video Calibration and Measurement SDK Software

Video Software Products – Broadcast, Post Production

• MultiScopeLite – Entry level video monitoring tool
• MultiScopeCompact V4.0.2 – Updated Pro video and audio monitoring tool
• Now supporting 3D video histogram scopes for WFM, Vectorscope color distribution
• Adding color cube scopes for out of gamut detection and verification
• High resolution integrated video monitor in 16:9 or 4:3 aspects
• Supports many PCI, RTSP Ethernet and USB computer video interfaces
• Processes a number of SD and HD video resolutions (480 to 1080)
• Calibrated ITU-R BT.601 and ITU-R BT.709 color spaces
• Supports display LCD resolutions of 1280×720 and better
• Accepts HDMI and SDI uncompressed SD and HD real-time video streams
• Supports Firewire, Thunderbolt, HDMI, SDI, composite, S-video, component
• Accepts BlackMagic, AJA, Microsoft, Hauppauge, Avermedia, Grass Valley…

Video SDK Library Functions – Engineering, Systems, Test

• 15 audiovideo analytical display port functions
• 2D-waveform monitor, vscope,RGBYCrCb Parade, Histo,VU,waveform,phase
• 3D-waveform monitor, vscope,RGBYCrCb Parade, RGBGamut YCrCb cube
• Built-in graphics display engine – just present audio or video data streams
• Simple function calls for real time audiovideo display
• Generic Open GL display features
• Comes with detailed Developers Guide
• 8bpp support only, wide range of frame resolutions and aspect ratios
• .Net development environment C++, C#, VB, MSStudio
• Built-in performance manager
• Multiple instances, multi-threaded

Graphics Software Products – Photography, Engineering

• Still motion version of MSCompact with same user controls and scopes
• Image analysis – color space, full RGB, YCrCb
• Uncompressed Bitmap file input only at this time
• Same access to both 2D and 3D scopes and controls
• Image resolutions to 4k x 4k in full 24bit color (8bit per pixel)
• Will accept any image aspect ratios
• Image data analyzed using recognized graphic analysis display tools
• Simple intuitive user interface – w/key property adjustments
• NEW — Full or BT709 BT601 masked gamut adjustment
• Pan-zoom and rotational controls in real-time for each scope

Follow my 3D Printed HD Telecine System Project – Jan 2019

• 1280×720 – 3D printed HD telecine system build using off the shelf parts
• 1920×1080, 2K and 4K upgrade path to be built-in
• Real-time system operation is planned — actual 24fps, 18fps and 15fps run times
• User set fixed and variable film indexing speeds (1fps to 24fps)
• Arduino (UNO / Due) is being used for test and system control,
• Complete fully described BOM (Bill of Materials) will be available
• All 3D print STL design files will be available
• Custom windows software application for camera control and streaming management
• Planned to handle 8mm, Super and 16mm films for now
• Upgrade path for 35mm academy film considered – 400ft or less for now
• Standard choice of HDMI, USB2 or USB3 interface, ext triggered cameras
• System budget is set to be less than $1000. Camera and lens ain’t cheap.

Software Application Development – Engineering, Scientific

• Custom digital video applications
• Imaging application development – Lumenera Cameras
• Custom hardware interfacing
• Testbed application development, protoyping
• Network application software – wireless, hard wired
• Custom telecine imaging and processing systems
• Digital Audio
• Signal analysis applications

Professional HD Film Transfers

• 2 Megapixel 4:4:4 uncompressed image capture
• Frame by frame imaging
• Quicktime YUV 4:2:2 files to DIY hard drive
• scene by scene colour/density correction available
• optional pro de-grain services. Cleans dust and light scratches
• Blu ray, AVCHD or film masters to SATA hard drives
• edge to edge film frame capture
• Guaranteed no flicker
• See HomeDVD.ca for Consumer and Professional video tape transfers
